Pure Fit TCL Large Tube Clamps
Pure Fit® Tube Clamps
-
Pure-Fit® TCL Large Tube Clamps provide the same innovative clamping
technology as Pure-Fit® TC, but are designed to accommodate large diameter
and thick wall tubing applications.
Pure-Fit® TCL is compatible with standard, braided (reinforced) and multilayer tubing. In addition to providing complete fluid stoppage, Pure-Fit® TCL can be utilized in the flow position and features an integral bore hole for absolute lock-out capabilities.
Item # |
Tubing Range, O.D. |
Tubing Range, Wall |
Material |
|---|---|---|---|
| PFTCL150 | Tubing Range, O.D. N/A 3/4 to 2 in | Tubing Range, Wall N/A 1/16 to 1/8 in | Material N/A PVDF |
| PFTCL250 | Tubing Range, O.D. N/A 3/4 to 2 in | Tubing Range, Wall N/A 1/8 to 1/4 in | Material N/A PVDF |
